How to determine the air supply plan for factory air compressor

How to determine the air supply plan for the factory air compressor is determined after comprehensive consideration and comparison of technical and economic conditions based on factors such as factory scale, distribution of gas consumption points, gas supply pressure level, and compressed air quality required to be supplied. Generally, there are 6 types of gas supply plans:

1. Set up regional compressed air stations for gas supply. When the factory is large in scale, the compressed air consumption is large and the main users are relatively dispersed, this plan is often used to reduce the pressure loss of the pipeline network and ensure the use of key gas. There should be pipelines connecting the regional station buildings to achieve the purpose of mutual load adjustment and mutual backup.

2. Set up several compressed air stations for gas supply. This plan is mainly used for small and medium-sized factories and large factories with relatively concentrated gas consumption.

3. On-site gas supply plan. When the gas consumption of the factory is not large, and the gas consumption points are few and scattered, it is possible to consider using a small air compressor unit to be placed near the starting point.

4. A combination of centralized and decentralized gas supply plan. In some large and medium-sized factories, the main compressed air consumption is relatively concentrated, and the secondary is relatively scattered. Especially at night when the gas consumption is less, this plan is suitable.

5. When the factory needs to supply different compressed air, and the low-pressure gas consumption is large, it should consider using gas supply systems with different pressure levels and configuring air compressors with different pressures. To reduce the energy waste caused by pressure reduction, but the gas supply pressure level should generally not exce

f31eeb9b6415cb420620cbad246561c7.5KW-5 ed two to reduce the initial equipment investment.

6. When some gas consumption points in the factory need to supply high-quality compressed air, you can consider using a single oil-free lubricated air compressor. You can also consider using the compressed air supplied centrally and supplying it after processing it with some post-processing equipment. The specific method to be used should be determined after comprehensive economic comparison based on the specific gas consumption and the location of the gas consumption point.


Post time: Mar-26-2025
